Thin Wall Nitinol Tubing Sizes Compared for Better Choices

A direct look at thin wall nitinol tubing sizes shows great accuracy and performance:

Careful control of wall thickness and outer size helps nitinol tubing meet tough medical rules. Medical devices need very exact sizes for good bend and strength. Special measuring tools keep the sizes right. This is important for safety, trust, and how well the device works. Picking the best thin wall nitinol tubing size gives the most bend, strength, and fit for each use.

Key Takeaways

• Thin wall nitinol tubing comes in exact sizes and fits tightly. This makes it strong, bendy, and dependable for tools in medicine and industry. Its special superelasticity and shape memory help it bend a lot. It can go back to its shape every time. This is great for medical devices that last long, like stents and catheters. Makers use advanced machines and careful checks to keep tubing safe. They make sure it works well with the body and meets medical rules. Picking the right tubing size, wall thickness, and finish helps devices fit better. It also makes them last longer and helps patients do better in surgeries and other uses. Wait times can change, so it is smart to work with good suppliers. They can give custom choices and quick help to keep projects moving and make sure tubing is high quality.

Size Overview

Outer Diameter Range

Nitinol tubing is made in many sizes. Some tubing is very small, only 0.1 mm wide. The biggest tubing can be 25 mm wide. Ultra-fine nitinol tubing can start at 0.003 inches. This makes it good for tiny medical tools. The table below lists common sizes and how close the sizes are kept:

These sizes help nitinol tubing work in many ways. It can be used in small catheters or big machines. Seamless tubing gives steady and strong results.

Wall Thickness Range

Wall thickness is important for how tubing bends and holds up. Ultra-fine nitinol tubing can be as thin as 0.0007 inches. Most tubing is between 0.001 inches and 1.00 mm thick. Ultra-fine tubing with thin walls is used in special medical tools. Thinner walls let tubing bend more. Thicker walls make tubing stronger. Seamless tubing with exact wall thickness works best in tough jobs.

Dimensional Tolerances

Tolerances show how much the size can change from what is wanted. Thin wall nitinol tubing has very tight tolerances. Some tubing can be made with OD tolerances as close as ±0.0005 inches. Wall thickness can be kept within ±0.0002 inches for ultra-fine tubing. Special tools like lasers and sound waves help keep these sizes right. Seamless tubing with tight tolerances works well, especially in medical tools. Even small changes in size can change how it works. Tight tolerances help tubing last longer and lower the chance of breaking. They also help the tubing keep its shape and bend. Seamless nitinol tubing with strict tolerances gives steady results. This makes it a top pick for important uses.

Note: Getting the size right and using seamless tubing is needed for nitinol tubing to meet tough rules and work well.

Thin Wall Nitinol Tubing Specs

Length and Crossing Profile

Thin wall nitinol tubing comes in many lengths. Most tubes are between 50 mm and 2,000 mm long. Some tubes can be made in special sizes for certain jobs. The crossing profile is the smallest width a device can have to fit through tight spots. This is very important when making medical devices. Ultra-fine nitinol tubing helps make very small crossing profiles. This is good for things like neurovascular stents and microcatheters. Seamless tubing gives smooth surfaces and steady results. It also helps lower friction when moving devices.

Popular sizes and finishes for thin-walled ni-ti tubes are:

Manufacturers keep sizes very close to what is needed. Seamless tubing helps keep high elastocaloric efficiency and superelasticity. These things are needed for medical devices that must move exactly inside the body.

Mechanical Properties

Thin wall nitinol tubing is special because of its mechanical properties. It has superelasticity, so it can bend a lot and go back to its shape. This is important for medical devices that need to bend and return many times. The elastocaloric effect means the tubing changes temperature when it is squeezed or stretched. This helps nitinol work better in busy places.

Mechanical tests use advanced tools like nanoindentation and X-ray diffraction. These tests check hardness, Young's modulus, and how the tubing stretches and shrinks. Researchers also look at how smooth the surface is. Smooth tubing is important for medical uses. Superelasticity and shape memory effects let nitinol recover from over 10% strain. This makes it good for devices that bend millions of times.

Clinical studies show nitinol tubing in neurovascular stents can handle up to 400 million pressure cycles. Devices with thin-walled ni-ti tubes can bend over 10 million times, which is more than a year of heartbeats. These devices can last 8 to 15 years, depending on where the stent is placed.

Nitinol is better than stainless steel and cobalt-chromium in flexibility and fatigue resistance. It also fits vessels better. The elastocaloric properties help nitinol work well in tough medical jobs. Seamless tubing makes it even stronger and longer-lasting.

Researchers check the mechanical properties of thin wall nitinol tubing with lab and animal tests. They focus on superelasticity, elastocaloric effect, and fatigue resistance. The tubing must work well in small, twisty blood vessels. It also needs to be safe for blood. Ultra-fine nitinol tubing with seamless construction and tight tolerances meets these needs. The elastocaloric effect and superelasticity help thin-walled ni-ti tubes keep their shape after many uses.

Thin wall nitinol tubing works very well in medical devices. Its fatigue resistance, elastocaloric efficiency, and superelasticity make it the best choice for jobs that need to last a long time.

Applications

Medical Devices

Nitinol tubing is very important in medicine. Companies pick tubing sizes and wall thickness for each tool. These tools include stents, catheters, and guidewires. For neurovascular stents, tubing is 0.2 mm to 2 mm wide. The wall thickness is 0.05 mm to 0.3 mm. This makes the tubing both flexible and strong. These sizes help tubing move through tricky blood vessels. The tubing does not kink or break.

Medical tools need very exact sizes. Special machines check tubing size within ±0.005 mm. Tests like ultrasonic and eddy current find any defects. These checks make sure tubing meets FDA and ISO 13485 rules. The tubing must be safe for the body and work well.

Clinical studies show nitinol stents keep their shape for over 190 days in animal tests. This helps patients do better for a long time.

The table below shows which tubing grades fit each medical use:

Nitinol tubing can stretch and return to its shape. This helps medical tools fit the body. The titanium oxide layer keeps the tubing safe and stops rust. This lowers bad reactions. These things help patients and make devices last longer. Thin wall tubing is picked for tools that must bend a lot and not kink.

Industrial Uses

Nitinol tubing is also used in factories and machines. Engineers use it in actuators, sensors, and special tools. The tubing can bend and go back to its shape. This is good for places where things move a lot.

Factory jobs often need bigger and thicker tubing for more strength. Wall thickness depends on how the tubing is made. Heat, speed, and wire feed all change the wall thickness. The table below shows how these things affect tubing:

Nitinol tubing does not rust and is safe for harsh places. It lasts a long time even when bent many times. Companies pick tubing sizes for each job. Some jobs need tubing to move just right or not wear out.

Specialty Applications

Nitinol tubing is also used in space, robots, and new medical tools. These jobs need special tubing with tight size rules. The tubing’s mix of metals, shape memory, and inside structure all matter.

Companies use lasers to make tubing as small as 1.61 mm wide. Wall thickness can be from 0.1 mm to 15 mm. Some tubes are up to 6000 mm long for special surgeries. Rules like ASTM F2063 make sure tubing is safe for surgery.

• The metal mix keeps tubing safe for the body and stops rust.

• Shape memory helps tubing work right in devices.

• The inside structure helps tubing last longer and not wear out.

Companies like Fort Wayne Metals, Resonetics, and Confluent Medical Technologies make custom tubing. They watch their supplies and use many sources to avoid delays. This keeps surgical tools safe and ready for doctors to use.

Tip: For special surgeries, always check that tubing is safe for the body and does not rust. This helps patients get the best results.

Choosing Nitinol Tubing

Flexibility and Strength

When picking nitinol tubing for surgery, you need to know about flexibility and strength. These things decide how well the tubing works in medical tools. Flexible nitinol tubing can bend a lot and snap back to its shape. This is called superelasticity. Stronger tubing can hold more weight but might not last as long if bent many times. The table below gives important numbers for medical use:

Flexible nitinol tubing has a tensile strength between 500 and 900 MPa. This makes it great for moving parts in surgery. Strong tubing is as tough as stainless steel but may not last as long if used over and over. Picking the right tubing helps it do its job well.

Compatibility

Compatibility is important when using nitinol tubing with other materials in medical tools. Engineers use special tests to look for tiny flaws and check the inside of the tubing. They also test how the tubing handles bending many times. This helps make sure the tubing will not break after lots of use. Friction tests with plastics like PEEK and PTFE show if the tubing will rub or damage other parts. These checks help make sure the tubing is safe for the body and works well in surgery.

Manufacturing Factors

How nitinol tubing is made changes how it works in medical tools. Things like laser settings, heat, and cutting methods change the tubing’s inside structure. Changing the energy during making can change how the tubing bends and snaps back. If the tubing gets too hot, some nickel can leave, which can change how safe it is for the body. Makers must watch these things closely to make good tubing for surgery. Careful control helps the tubing stay strong, bendy, and safe every time.

Sourcing Thin-Walled Ni-Ti Tubes

Standard vs. Custom

Manufacturers make both standard and custom nitinol tubing. Standard tubing fits most needs and follows strict rules. Custom tubing has special sizes, finishes, and better fatigue resistance. Both types must pass quality checks like ASTM F2063, ISO 10993, and ISO 13485. Suppliers use advanced controls, such as electropolishing and many tests, to check quality. Custom tubing gets extra checks, like fast durability tests and tighter size limits. Suppliers keep records, track each tube, and give technical help. These steps help tubing meet medical rules and stay safe.

• Standard tubing: Already made, meets basic rules, fast to get.

• Custom tubing: Made for special tools, better fatigue resistance, more checks.

• Both types: Need quality systems, follow rules, and have supplier help.

Lead Times

Lead times for nitinol tubing have changed a lot. Before the pandemic, tubing arrived in 10-12 weeks. Now, it can take almost a year to get tubing. Delays happen because drilling takes longer and new drillers need checking. Some suppliers, like Resonetics, have made lead times better. They hired more drillers and keep materials ready at each step. They can give prices fast and make samples in 1-2 weeks if they have materials. These changes help shorten wait times and keep projects moving.

• Typical lead times: 10-12 weeks before, now up to a year.

• Causes: Drilling takes longer, checking new drillers, more steps after drilling.

• Solutions: More drillers, kanban systems, fast prices for samples.

Quality and Certification

Quality and certifications are very important for nitinol tubing. Suppliers must follow strict rules like ASTM F2063, ISO 10993, and ISO 13485. Both standard and custom tubing need strong tests for strength, rust resistance, and safety in the body. Suppliers use special controls and tools to keep sizes exact. Custom tubing gets extra checks and paperwork to meet medical rules. Following rules, FDA guides, and quality systems keeps tubing safe and working well. Suppliers give full records and help to meet all rules.

Tip: Always make sure nitinol tubing has all needed certifications and passes quality checks before using it.

Thin wall nitinol tubing comes in many sizes and types for surgery. Each type has its own level of flexibility, strength, and quality. The table below shows how different nitinol materials help stop blood and fibrin from building up on medical devices. This helps patients get better results:

Picking the right nitinol tubing helps medical tools work their best. It also helps patients do better after surgery. For special surgeries, doctors should talk to suppliers to make sure they get the best tubing. This helps make sure the tubing fits and works well.

FAQ

What makes nitinol tubing different from other metal tubing?

Nitinol tubing is special because it can bend and snap back. This is called superelasticity and shape memory. It means the tubing goes back to its shape after bending. Many companies use nitinol tubing because it is flexible and strong. It also lasts a long time.

How do manufacturers ensure nitinol tubing meets strict size requirements?

Manufacturers use high-tech tools to check nitinol tubing. They measure the outside and wall thickness with lasers and sound waves. These checks keep the tubing size very exact. This helps every tube meet the rules for its size.

Which industries use nitinol tubing most often?

Medical device makers use nitinol tubing for stents and catheters. Aerospace and robotics companies also use it for its special features. Engineers pick nitinol tubing when they need something flexible and tough.

Can nitinol tubing be customized for special projects?

Suppliers can make nitinol tubing in special sizes and finishes. They change the tubing’s size and wall thickness for each job. Custom tubing helps new medical and industrial tools work better. Engineers ask for special tubing for new ideas.

What certifications should buyers look for when sourcing nitinol tubing?

Buyers should look for certifications like ASTM F2063 and ISO 10993. ISO 13485 is also important for medical tubing. These show the tubing is safe and high quality. Certified tubing is trusted for medical and factory use.
