What Are the Dimensions of 0.2mm Wall Thickness Nitinol Tubing for Micro Catheters

AccuPath

·May 21, 2025

·10 min read

What Are the Dimensions of 0.2mm Wall Thickness Nitinol Tubing for Micro Catheters — Image Source: unsplash

Precise sizes affect how 0.2mm wall thickness nitinol tubing for micro catheters works. The tubing usually has an outer width of 0.6mm and an inner width of 0.4mm. Its length can be adjusted from 10cm to over 150cm. These features make it flexible and prevent bending problems, which is important for moving through tiny blood vessels.

Nitinol is very useful in medicine because of its special traits. It can bend without snapping and goes back to its original shape. This makes 0.2mm wall thickness nitinol tubing for micro catheters perfect for creating microcatheters. It is also safe to use with human tissue during medical procedures.

Key Takeaways

Nitinol tubing with 0.2mm walls has a 0.6mm outer diameter and a 0.4mm inner diameter. It works well in small blood vessels.
Nitinol is special because it can bend and return to its shape. This helps it work better in medical treatments.
You can customize nitinol tubing in lengths from 10cm to over 150cm. It can also have features like markers that show up on X-rays.
The tubing is safe for the body because it doesn’t rust and works well inside for a long time. This lowers the chance of problems during surgeries.
Nitinol tubing is used in many surgeries, like heart and brain ones. It is strong, flexible, and dependable.

Importance of 0.2mm Wall Thickness Nitinol Tubing for Micro Catheters

Unique Properties of Nitinol

Nitinol is special because of its amazing traits. These make it great for medical tools like microcatheters. Its shape memory effect lets it return to its original shape after bending when heated. This helps devices stay useful even if twisted or bent. Another important trait is superelasticity, which lets nitinol bend a lot without breaking. This flexibility is key for moving through narrow blood vessels.

The table below shows nitinol's unique traits:

Property	Description
Shape Memory Effect	Goes back to its original shape when heated.
Superelasticity	Bends a lot and recovers without needing heat.
Biocompatibility	Safe for the body due to a protective titanium oxide layer.
Corrosion Resistance	Stays strong and resists damage in the body.
Fatigue Resistance	Handles repeated stress without wearing out.

These traits make 0.2mm wall thickness nitinol tubing reliable for tough conditions.

Role of Nitinol in Micro Catheter Design

Nitinol is very important in making microcatheters, especially with a 0.2mm wall thickness. Its strength and flexibility help the tubing fit into blood vessels easily. This makes it safer and easier to use. Nitinol is also lightweight but strong, which keeps the tubing durable.

Some design benefits include better visibility and easy adjustments. Radiopaque marker bands, added to nitinol microcatheters, help doctors place them accurately. Also, nitinol's superelasticity lets doctors move or adjust the catheter during procedures. This gives them more control.

The table below explains nitinol's role in microcatheter design:

Feature	Description
Material	Nitinol braiding adds strength and flexibility.
Design Benefit	Fits blood vessels for smoother movement.
Migration Minimization	Helps keep the catheter in place during use.
Visibility	Radiopaque markers make placement easier.
Repositioning Capability	Lets doctors adjust the catheter's position as needed.

These features make nitinol tubing with a 0.2mm wall thickness essential for top-quality microcatheters.

Dimensions and Specifications of 0.2mm Wall Thickness Nitinol Tubing

Inner Diameter, Outer Diameter, and Wall Thickness

Precision is key for 0.2mm wall thickness nitinol tubing. The outer diameter is 0.6mm, and the inner diameter is 0.4mm. These sizes give the tubing strength and flexibility. The 0.2mm wall thickness keeps it strong but bendable. This helps it move through narrow blood vessels easily.

These dimensions make the tubing perfect for microcatheters. The outer size works with many medical tools. The inner size allows guidewires or fluids to pass smoothly. Careful design improves how the tubing works in delicate medical tasks.

Length and Customization Options

The tubing length can change based on what’s needed. Standard lengths range from 10cm to over 150cm. This lets you pick the right size for short or long procedures.

Customization is another big benefit. Companies like AccuPath can make tubing to fit your needs. You can ask for specific lengths, sizes, or extra features like radiopaque markers. These markers help doctors see the tubing better during procedures. Custom options ensure the tubing fits your medical needs perfectly.

Manufacturing Tolerances and Standards

Making 0.2mm wall thickness nitinol tubing follows strict rules. Medical-grade tubing usually has a wall thickness between 0.1mm and 0.3mm. Sizes are kept accurate within ±0.01mm or better. This ensures top quality.

The table below shows size tolerances for outer diameters:

Outer Diameter (OD) Range mm	Tolerance mm
≤ 0.3	±0.005
0.3 ≤ OD ≤ 0.5	±0.007
0.5 ≤ OD ≤ 1.5	±0.015

Manufacturers must also follow strict safety rules. Standards like FDA 21 CFR Part 820 and ISO 13485 guide the process. Each batch is tested for safety, material quality, and sterilization. ASTM F2063 ensures nickel levels stay safe for patients.

These rules and tests make sure the tubing works well in medical use. Choosing trusted companies like AccuPath gives you safe and reliable tubing for your procedures.

Performance Implications of 0.2mm Wall Thickness

Kink Resistance and Flexibility

The 0.2mm nitinol tubing resists kinks and stays flexible. These traits are vital for microcatheters in tricky blood vessels. Its superelasticity lets it bend without staying bent. This helps it move smoothly through tight, curvy pathways. It also lowers the chance of problems during procedures.

A study shows how this tubing improves control in stent systems. Over 60% of doctors said nitinol made handling easier. Thin tubing is also in high demand for brain surgeries. These surgeries need tools that are both precise and flexible.

Evidence Description	Percentage
Nitinol tubing improves stent system control	Over 60%
High demand for thin tubing in brain surgeries	High

These facts show why this tubing is so important in delicate surgeries.

Pushability and Trackability

Pushability and trackability are key for microcatheter success. The 0.2mm nitinol tubing performs well in both areas. Its light but strong design helps it move easily in blood vessels. The tubing’s exact size and even walls keep it steady while moving.

Pushability means you can guide the catheter with little effort. Trackability ensures it stays on the right path. This is crucial for placing devices accurately. These features make procedures faster and safer.

Biocompatibility and Durability

Nitinol tubing is safe for the body and lasts a long time. Its titanium oxide layer protects it when touching human tissue. This reduces the chance of bad reactions during surgeries.

The tubing resists rust, making it reliable inside the body. Studies show it stays strong and flexible over time. Special manufacturing methods make it handle repeated use without breaking.

Key features of nitinol tubing include:

Safe for medical use with human tissue.
Rust resistance for long-term use.
Keeps strength and flexibility over time.
Made to handle repeated stress without damage.
Meets strict ISO and ASTM material standards.
FDA-approved for safety and quality checks.

These qualities make nitinol tubing a dependable choice for microcatheters. It ensures safety and durability in medical procedures.

Uses of 0.2mm Wall Thickness Nitinol Tubing in Medicine

Peripheral Vascular Treatments

Nitinol tubing is very useful in vascular treatments. Its bendability and strength make it great for stents. These stents help fix narrow or blocked blood vessels. Studies show it works well to keep vessels open.

Stents stayed in place with no major problems.
Lumen loss dropped from 27.3% at 30 days to 17% at 360 days.
Stents were fully covered, stopping blood clots from forming.

These features make nitinol tubing safe and reliable for vascular care.

Heart Procedures

Nitinol tubing is important in heart-related devices like closure systems. Its safety and strength lead to good results. A study by Burke et al. showed its success:

Study Name	Results
StarClose Vascular Closure System (VCS) is Safe and Effective in Patients Who Ambulate Early Following Successful Femoral Artery Access Closure - Results from the RISE Clinical Trial	The StarClose system is safe and works well for patients walking soon after artery closure.

This proves nitinol tubing is dependable for heart procedures, ensuring safety and success.

Brain Treatments

Nitinol tubing improves results in brain-related surgeries. It fits tricky blood vessel paths, helping place stents and catheters accurately. Its special traits boost safety and healing.

Nitinol lowers risks by reducing bad reactions during surgery.
Its flexibility helps stents fit complex paths, easing recovery and pain.
It lasts long, handling millions of heartbeats without breaking.
Shape memory and safety make it reliable for long-term use.

These benefits make nitinol tubing a must-have for brain surgeries, where accuracy and safety are crucial.

The size of 0.2mm wall thickness nitinol tubing is important. It has a 0.6mm outer diameter and a 0.4mm inner diameter. Its length can be customized for different uses. These exact sizes help it stay strong, flexible, and move easily in tight blood vessels. This makes it very useful for medical treatments.

Nitinol has special features like shape memory and superelasticity. Shape memory lets it return to its original shape after bending. Superelasticity helps it handle heavy bending without breaking. These qualities make the tubing resist kinks and last longer, even in tough conditions.

Metric	What It Means
Fatigue Life	Stays strong even after being used many times.
Tensile Strength	Shows how well it holds its shape under pressure.
Residual Elongation	Checks how it behaves under stress for safe use.

Nitinol tubing is also safe for the body and resists rust. This makes it work well inside the body for a long time. These features help doctors perform less invasive surgeries and improve patient care.

Nitinol tubing adjusts to tricky body pathways and meets healthcare needs. It is a game-changing material in today’s medical world.

FAQ

Why is nitinol tubing great for microcatheters?

Nitinol tubing has special traits like superelasticity, shape memory, and being safe for the body. It can bend without breaking and return to its shape. These features make it ideal for moving through small, tricky blood vessels.

Can nitinol tubing sizes be customized?

Yes, you can customize the length, inner size, and outer size. You can also add features like radiopaque markers to help doctors see better during procedures. Custom options make sure the tubing fits your medical needs.

How does a 0.2mm wall thickness help?

A 0.2mm wall thickness gives both strength and flexibility. It stops kinking, improves pushability, and moves smoothly in tight spaces. This thickness also makes the tubing strong enough for repeated use.

Is nitinol tubing safe for long-term use?

Yes, nitinol tubing is safe and resists rust. Its titanium oxide layer protects it from causing bad reactions with the body. It meets strict rules like ISO 13485 and ASTM F2063, making it safe for long-term use.

What surgeries use nitinol tubing?

Nitinol tubing is used in heart, blood vessel, and brain surgeries. It works well for stents, microcatheters, and closure systems. Its flexibility and strength make it perfect for precise, less invasive surgeries.

Tip: Always work with trusted companies to get tubing that fits your needs.
